ALADIN EnO receiver, 2-channel / 12V / 300767

For light / ventilation and general controls
2-channel radio receiver (12V) for switching low voltage equipment, lighting and other electrical consumers. Each channel can be individually controlled with div. ALADIN transmitters and assigned with different functions and parameters (up to 90 different settings). Several transmitters with different functions can be stored on the same channel. The teach-in is done in a simple way via professional rotary switches and buttons. The receiver has repeater function and status display of active outputs. The receiver can also be controlled by transmitters with the latest secure encryption. For optimal radio reception in flush mounting (1×1), the receiver has a mounting system newly developed by Flextron. Ecologically manufactured housing, made of 92% recycled plastic. Made in Switzerland / Swiss Made

Function:

• 2-button function (standard)
• 2-button function with switch-off delay
• 2-button function with flashing (e.g. siganlization in doors)
• 1-button function
• 1-button function for hand transmitter
• Impulse function (without/with emergency stop)
• Impulse function (without/with an emergency stop) with inverting switching
• Minutery (without/with a shutdown warning), staircase light (times: 2 – 120 min)
• Safe control of PLC with short -term: 1S / 5S / 30S
• Fan function with flow / after-run times (various terms)
• Control for door / window monitoring (window contact / window handle)
• Acceleration sensor (multisensor)
• Motion detector as a full /semi-automatic (various values)
• Light sensor / moisture sensor (multisensor)
• HotelCard switch (various values)
• Scene control (light etc.)
• Repeater function adjustable
• Reboot behavior adjustable (after interruption of tension)
• With assembly brain for better radio reception (e.g. up. Up installation with blind lid)
• Each function has various parameters (times, values, rocker occupancy, etc.)

Application area:

• Control of small voltage systems (12V)
• Control of lighting
• Control of doors
• Siganlization
• Minute
• Impulse control
• Control of SPS
